| 规格公制 Metric System | 规格英制 Inch System | 型状编号 Shape | 组织等级 Specification | M/S | RPM | 包装片数 PCS/CTN |
T27 | AWA24QBF | |||||
| 76*6*9.53 | 3*1/4*3/8 | 076801 | AWA24QBF | 80 | 20100 | 200 |
| 100*4*16 | 4*1/6*5/8 | 100802 | AWA24QBF | 80 | 15300 | 200 |
| 100*6*16 | 4*1/4*5/8 | 100801 | AWA24QBF | 80 | 15300 | 200 |
| 115*4*22 | 4-1/2*1/6*7/8 | 115802 | AWA24QBF | 80 | 13300 | 100 |
| 115*6*22 | 4-1/2*1/4*7/8 | 115801 | AWA24QBF | 80 | 13300 | 50 |
| 125*6*22 | 5*1/4*7/8 | 125801 | AWA24QBF | 80 | 12200 | 100 |
| 150*6*22 | 6*1/4*7/8 | 150801 | AWA24QBF | 80 | 10200 | 100 |
| 180*4*22 | 7*1/6*7/8 | 180802 | AWA24QBF | 80 | 8500 | 50 |
| 180*6*22 | 7*1/4*7/8 | 180801 | AWA24QBF | 80 | 8500 | 25 |
| 180*8*22 | 7*1/3*7/8 | 180803 | AWA24QBF | 80 | 8500 | 50 |
| 200*6*22 | 8*1/4*7/8 | 200801 | AWA24QBF | 80 | 7400 | 25 |
| 230*4*22 | 9*1/6*7/8 | 230802 | AWA24QBF | 80 | 6600 | 25 |
| 230*6*22 | 9*1/4*7/8 | 230801 | AWA24QBF | 80 | 6600 | 25 |
| 230*8*22 | 9*1/3*7/8 | 230803 | AWA24QBF | 80 | 6600 | 25 |
| 115*6*16-11 | 4-1/2*1/4*5/8-11 | 115804 | AWA24QBF | 80 | 13300 | 50 |
| 180*6*16-11 | 7*1/4*5/8-11 | 180804 | AWA24QBF | 80 | 8500 | 25 |
| 200*6*16-11 | 8*1/4*5/8-11 | 200804 | AWA24QBF | 80 | 7400 | 25 |
| 230*6*16-11 | 9*1/4*5/8-11 | 230804 | AWA24QBF | 80 | 6600 | 25 |
